Allen-Bradley 2094-BL25S AC Drive
- Extended Product Type: AC Drive
- Product ID: 2094-BL25S
- Allen-Bradley Type Designation: AC Drive
Description of Allen-Bradley 2094-BL25S AC Drive
The Allen-Bradley 2094-BL25S module is a line interface module and it belongs to the 2094 Kinetix product line. It has a voltage rating of 400 Volts AC, and auxiliary output of 20 Amps at 24 Volts DC and of 25 Amps at 230 Volts AC.
Specifications of Allen-Bradley 2094-BL25S AC Drive
- Brand : Allen-Bradley
- Series : Kinetix 6000
- Product Type : Line Interface Module
- Bulletin : 2094
- Phase : 3
- Voltage : 400 V AC
- Output Current : 25 A at 230 V AC
- Feature : Circuit Branch Protection
- Wattage : 42.9 Watts
- Operating Temperature Range : 0 to 50 Degrees Celsius
The 2094-BL25S line interface module has been manufactured by Allen-Bradley/Rockwell Automation. It belongs to the 2094 product like of Kinetix interface modules. The module has a voltage rating of 400 Volts AC, an auxiliary output current of 25 Amps at 230 Volts AC, and one of 20 Amps at 24 Volts DC. It also features a configurable branch circuit protection option and it has estimated dimensions of 10.3 x 15 x 9.8 inches and an approximate weight of 37.8 pounds or 17.15 kilograms. Other notable specifications of the 2094-BL25S line interface module include a contactor pickup time of 18.5 milliseconds minimum and of 30 milliseconds maximum. It also has a contactor dropout time of 10 milliseconds at the minimum and 60 milliseconds at the maximum. The module has a rated power output dissipation of 42.9 Watts. The 2094-BL25S module has an operating temperature range of 0 to 50 degrees Celsius or 32 to 122 degrees Fahrenheit and a storage temperature range of -40 to 70 degrees Celsius or -40 to 158 degrees Fahrenheit.
The Allen-Bradley 2094-BL25S line interface module and the entire Bulletin 2094 product line of Kinetix line interface modules have a non-condensing humidity range of 5 to 85 percent. This line interface module performs best at elevations of up to 1000 meters or 3300 feet above sea level without de-rating. However, the continuous current rating needs to be de-rated by 3 percent for avery additional 300 meters of altitude for up to 3000 meters of total maximum operating altitude. The maximum vibration of the 2094-BL25S line interface module when operating is 0.152 millimeters of peak-to-peak displacement, and 1 G of peak acceleration at 5 to 2000 Hertz. Also, while operating, this line interface module has a maximum shock tolerance of 11 G and 11 milliseconds of half-sine pulse.
