Robust Construction: Durable sensor design with stainless steel wetted parts
-
High Accuracy: Precise output over the specified pressure range
-
Wide Operating Temperature: Stable performance across varying environments
-
Standard Electrical Interface: Easy integration with PLCs, controllers, and data acquisition systems
-
Compact Size: Space-efficient for panel and field installations
-
Excellent Long-Term Stability: Low drift over time
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer Part Number | 060G6287 |
| Model | MBS 3350-2011-A1AC04-0 |
| Pressure Type | Gauge / Relative (verify on specific ordering code) |
| Pressure Range | 0–2011 bar (verify specific calibration) |
| Accuracy | Typically ±0.5% FS (may vary by variant) |
| Supply Voltage | +9 … +32 VDC (typical) |
| Output Signal | 4 … 20 mA (2-wire) |
| Operating Temperature | -40°C to +125°C |
| Compensated Temperature Range | -20°C to +85°C |
| Wetted Materials | Stainless Steel ASTM 316L or equivalent |
| Process Connection | G1/4, 1/4″ NPT, or other (confirm at order) |
| Electrical Connection | DIN 43650/ISO 4400 or equivalent |
| Response Time | ≤ 1 ms |
| Protection Rating | IP65 / IP67 (environment dependent) |
| Shock Resistance | 100 g |
| Vibration Resistance | 10 g |
| Certifications/Approvals | CE, RoHS (other options depending on variant) |
Operating Principle
The transmitter uses a piezoresistive sensing element isolated by a diaphragm exposed to the fluid pressure. The diaphragm deflects proportionally to applied pressure, and the sensor converts this deflection into a standardized 4-20 mA electrical signal for precise monitoring and control.
Typical Applications
-
Hydraulic and pneumatic systems
-
Industrial automation and process control
-
Mobile machinery and construction equipment
-
Test benches and OEM applications
-
Oil & gas pressure measurement
-
Water treatment and pump control systems
Installation Guidelines
-
Install with correct orientation for best accuracy
-
Use appropriate torque on process connection to avoid sensor damage
-
Ensure proper sealing (PTFE tape or compression fitting)
-
Route electrical cable to avoid excessive bending near the sensor
-
Protect against vibration and impact where possible
Performance and Reliability
-
Low hysteresis and repeatability error
-
Stable output under temperature changes
-
Durable construction suitable for harsh environments
-
Designed for continuous industrial duty
Environmental and Safety Ratings
-
High ingress protection (minimum IP65)
-
Resistant to shock and vibration
-
Compliance with industry safety/environmental standards
-
Electrostatic discharge protection where applicable
Optional Accessories
-
Mating connector / cable harness
-
Protective cap or boot
-
Mounting bracket
-
Calibration certificate
Packaging & Documentation
-
Individually boxed with protective materials
-
Includes product label & serial number
-
Supplied with basic installation instructions
-
Optional detailed datasheet and calibration report
Warranty
Standard manufacturer warranty applies (typically 12 months), subject to Danfoss terms and conditions. Warranty may vary based on application and installation practices.
Summary Specification Table
| Parameter | Specification |
|---|---|
| Model | MBS 3350-2011-A1AC04-0 |
| Part Number | 060G6287 |
| Pressure Range | Up to 2011 bar (confirm specific variant) |
| Output | 4–20 mA |
| Supply | +9–32 VDC |
| Accuracy | ±0.5% FS (typical) |
| Wetted Material | Stainless Steel |
| Protection | IP65 / IP67 |
| Operating Temp | -40°C to +125°C |
