High Accuracy: Precise measurement with minimal drift
-
Sturdy Construction: Stainless steel diaphragm and wetted parts for corrosion resistance
-
Wide Operating Range: Suitable for moderate to high pressure systems
-
Standard Output Signals: Compatible with modern control systems
-
Temperature Compensation: Ensures stable performance across operating temperature range
-
Vibration & Shock Resistant: Reliable in industrial environments
-
Compact & Versatile: Easy installation and integration
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Pressure Transmitter |
| Model / Configuration | MBS 3350-2011-A1AC04-0 |
| Manufacturer | Danfoss |
| Part Number | 060G6346 |
| Pressure Type | Gauge (or specify absolute if applicable) |
| Pressure Range | 0–2011 kPa (or as defined by “2011” suffix) |
| Maximum Pressure | Generally 3× rated (verify in datasheet) |
| Output Signal | Typically 4–20 mA (or other specified output) |
| Supply Voltage | Commonly +9–32 V DC |
| Accuracy | ±0.5% FS typical (subject to factory calibration) |
| Operating Temperature | Ambient: –40°C to +125°C (verify exact range) |
| Media Temperature | –40°C to +125°C |
| Electrical Connection | DIN connector or cable (model specific) |
| Process Connection | Threaded (e.g., 1/4″ NPT or BSP) |
| Wetted Materials | Stainless steel |
| Protection Rating | IP65 / IP67 (verify specific rating) |
| Response Time | ≤10 ms (typical) |
| Certifications | CE, RoHS compliant |
Operating Principle
The Danfoss MBS 3350 series uses a precision strain gauge sensor bonded to a flexible diaphragm. When process pressure is applied, the diaphragm deflects, producing an electrical signal proportional to the pressure level. This signal is conditioned and output as a standard analog signal suitable for direct interface with controllers, PLCs, and monitoring systems.
Applications
-
Industrial automation systems
-
Hydraulic and pneumatic pressure monitoring
-
Refrigeration and HVAC pressure control
-
Compressor protection and monitoring
-
Process control instrumentation
-
Building management systems (BMS)
Installation Guidelines
-
Mount transmitter in a stable location free from excessive vibration
-
Use proper thread sealant on process connection
-
Ensure correct electrical polarity and shielded wiring where appropriate
-
Avoid installing near high-temperature sources without proper shielding
Environmental and Safety Ratings
-
Designed for industrial environments
-
Withstands shock and vibration
-
Corrosion resistant stainless steel housing
-
Meets relevant safety and EMC standards
Packaging and Handling
-
Anti-static protective packaging
-
Labeled with part number, serial number, and calibration info
-
Includes instruction leaflet and warranty information
Warranty
Standard manufacturer warranty (typically 12 months from delivery or commissioning, subject to Danfoss terms and conditions).
Accessories and Options
-
Mating connectors and cable assemblies
-
Mounting brackets
-
Protective covers
-
Calibration certificates on request
Summary
The Danfoss 060G6346 (MBS 3350-2011-A1AC04-0) Pressure Transmitter delivers:
-
Reliable pressure measurement
-
Industry-grade construction
-
Standard electrical interface for automation
-
Excellent stability across temperature and operating conditions
-
Ideal for industrial, HVAC/R, and process control applications.
