Robust Construction: Durable stainless steel wetted parts and diaphragm for harsh environments
-
Reliable Measurement: High accuracy and long-term stability
-
Wide Operating Range: Suitable for low and high pressure systems (specific range defined)
-
Standardized Output: Compatible with PLCs, controllers, and data acquisition systems
-
Temperature Compensation: Maintains accuracy across temperature variations
-
Compact Design: Easy installation in constrained spaces
-
Electromagnetic Compatibility: Designed to meet industrial EMC standards
Technical Specifications
| Specification | Details |
|---|---|
| Model | MBS 4010-6231-D8CB11-2 |
| Part Number | 060G6357 |
| Pressure Type | Gauge / Absolute (as configured) |
| Pressure Range | Specify range (e.g., 0–400 bar) |
| Accuracy | ±% of full scale (refer to Danfoss datasheet) |
| Supply Voltage | Typical (e.g., +10 to +30 V DC) |
| Output Signal | Industrial standard (e.g., 4–20 mA) |
| Response Time | ≤ X ms |
| Operating Temperature | e.g., −40 °C to +125 °C |
| Storage Temperature | e.g., −40 °C to +125 °C |
| Material (Wetted Parts) | Stainless steel |
| Process Connection | Thread (e.g., M12×1.5, 1/4″ NPT) |
| Electrical Connection | Connector (e.g., DIN, Packard, or cable version) |
| Protection Rating | IP67 (dust and water protection) |
| Certifications | CE and industry-specific standards |
Operating Principle
The transmitter senses pressure via a diaphragm element. As pressure changes, the diaphragm deflects. This mechanical change is transformed into an electrical signal by internal sensing electronics. The conditioned output signal (typically 4–20 mA or voltage) is proportional to pressure, allowing accurate remote monitoring and control.
Typical Applications
-
Hydraulic systems monitoring
-
Industrial process control
-
Mobile machinery (construction, agriculture)
-
HVAC & refrigeration systems
-
Water and fluid distribution systems
-
Automation and safety systems
Installation Guidelines
-
Mount the transmitter in a location with minimal vibration and heat sources
-
Ensure correct process connection and thread sealing
-
Check orientation as recommended by Danfoss
-
Connect power and signal wiring according to pinout
-
Confirm device grounding and shielding to avoid noise interference
Environmental and Performance Ratings
-
Designed for industrial environments
-
Resistant to shock and vibration
-
Suitable for fluid media compatible with stainless steel
-
Electromagnetic compatibility in line with industrial standards
Accessories and Options
-
Connectors: DIN, Packard, or cable
-
Mounting adapters and brackets
-
Protective covers and boots
-
Calibration certificates (optional)
-
Customization for different pressure ranges or outputs
Packaging and Identification
-
Anti-static packaging
-
Product label with serial number and model code
-
Includes warranty documentation and installation guide
Warranty and Support
Standard manufacturer warranty (typically 12 months) applies, subject to Danfoss terms and conditions. Technical support is available through authorized Danfoss distributors.
Summary Specification
| Attribute | Value |
|---|---|
| Model | MBS 4010-6231-D8CB11-2 |
| Part No. | 060G6357 |
| Output | e.g., 4–20 mA |
| Supply | e.g., +10–30 V DC |
| Accuracy | ±% FS |
| Temp Range | e.g., −40 to +125 °C |
| Protection | IP67 |
