Endress+Hauser E+H FMP54-IBACCAAED1AAJ+AAEFF4IJJAKDKEZ1 Guided Radar FMP54IBACCAAED1AAJAAEFF4IJJAKDKEZ1

• Extended Product Type: Transmitter

• Product ID: FMP54-IBACCAAED1AAJ+AAEFF4IJJAKDKEZ1

• E+H Type Designation: Transmitter

Description of Endress+Hauser FMP54-IBACCAAED1AAJ+AAEFF4IJJAKDKEZ1 Guided Radar Level Transmitter

The Endress+Hauser FMP54-IBACCAAED1AAJ+AAEFF4IJJAKDKEZ1 Guided Radar Level Transmitter is a high-performance level measurement device designed for accurate and reliable monitoring of liquids in industrial storage and process tanks. As part of the Endress+Hauser Levelflex FMP54 series, this instrument uses guided wave radar (GWR) technology to provide precise level measurements even under difficult process conditions.

The FMP54 transmitter operates using Time Domain Reflectometry (TDR) technology, where radar pulses travel along a probe and reflect back when they encounter the surface of the product. This method allows the instrument to measure levels with exceptional accuracy regardless of vapor, temperature fluctuations, foam, or changing dielectric constants.

Built for demanding industrial environments, the FMP54 is widely used in industries such as chemical processing, oil and gas, power generation, water treatment, and industrial manufacturing. Its robust housing, advanced signal processing, and flexible communication capabilities ensure seamless integration with modern control systems.

This guided radar level transmitter offers continuous level measurement, minimal maintenance requirements, and long-term operational stability. The advanced electronics and intelligent diagnostics enable predictive maintenance and help improve overall plant reliability.

With its modular design and high measurement precision, the FMP54-IBACCAAED1AAJ+AAEFF4IJJAKDKEZ1 is an ideal solution for facilities seeking reliable, accurate, and maintenance-free level monitoring for a wide range of liquid applications.

Technical Specifications of E+H FMP54-IBACCAAED1AAJ+AAEFF4IJJAKDKEZ1 Guided Radar

Parameter	Specification
Manufacturer	Endress+Hauser
Model	FMP54-IBACCAAED1AAJ+AAEFF4IJJAKDKEZ1
Product Series	Levelflex FMP54
Measurement Principle	Guided Wave Radar (Time Domain Reflectometry)
Application	Continuous level measurement for liquids
Measuring Range	Up to 40 m (131 ft) depending on probe type
Accuracy	±2 mm
Process Temperature Range	-40°C to +150°C (-40°F to +302°F)
Process Pressure Range	Up to 40 bar (580 psi)
Output Signal	4–20 mA HART
Communication Protocols	HART, optional digital communication
Power Supply	10.5 – 35 V DC
Process Connection	Threaded or flanged options
Probe Type	Rod, cable, or coaxial
Housing Material	Aluminum or stainless steel
Protection Rating	IP66 / IP67
Hazardous Area Approvals	ATEX, IECEx, FM (depending on configuration)
Installation	Top-mounted on tanks or vessels

Key Features of E+H FMP54-IBACCAAED1AAJ+AAEFF4IJJAKDKEZ1 Guided Radar

1. High Precision Level Measurement

The FMP54 provides extremely accurate liquid level readings using guided radar technology, ensuring reliable monitoring for critical industrial processes.

2. Advanced Guided Wave Radar Technology

The transmitter uses radar pulses guided along a probe to measure liquid levels precisely, minimizing interference from vapor, foam, or temperature changes.

3. Robust Industrial Design

Built for harsh environments, the device features corrosion-resistant materials and rugged construction to withstand demanding industrial conditions.

4. Wide Measuring Range

The FMP54 supports measuring ranges up to 40 meters, making it suitable for large storage tanks and process vessels.

5. Easy Integration with Control Systems

With standard 4–20 mA HART output, the transmitter integrates seamlessly with PLCs, SCADA systems, and distributed control systems.

6. Low Maintenance Operation

Guided radar technology requires minimal calibration and maintenance, reducing operational costs and downtime.

7. Flexible Probe Options

The transmitter supports multiple probe configurations including rod, cable, and coaxial designs for different tank geometries and process conditions.

8. Smart Diagnostics

Built-in diagnostics provide continuous monitoring of device health and process conditions, enabling predictive maintenance and improved plant reliability.

Applications of E+H FMP54-IBACCAAED1AAJ+AAEFF4IJJAKDKEZ1 Guided Radar

The Endress+Hauser FMP54-IBACCAAED1AAJ+AAEFF4IJJAKDKEZ1 Guided Radar Level Transmitter is widely used across industries where accurate liquid level measurement is essential.

Chemical Processing

Used to monitor liquid levels in chemical storage tanks, reactors, and mixing vessels where stable and reliable measurements are required.

Oil and Gas Industry

Provides precise level measurement in storage tanks, separators, and processing units.

Power Generation

Used in boiler feedwater tanks, condensate tanks, and cooling systems.

Water and Wastewater Treatment

Ensures accurate level monitoring in treatment tanks, reservoirs, and pumping stations.

Food and Beverage Industry

Helps maintain precise liquid levels in storage vessels and production processes.

Industrial Manufacturing

Suitable for monitoring liquids in processing tanks and bulk storage systems.

Advantages of Guided Radar Level Measurement

Guided radar technology provides several advantages compared to traditional measurement methods such as float switches, ultrasonic sensors, or differential pressure transmitters.

• Higher measurement accuracy
• Reliable performance in vapor and foam
• Insensitive to temperature or pressure changes
• Minimal calibration requirements
• Stable measurement for varying product properties

These benefits make guided radar transmitters like the FMP53 an ideal solution for modern industrial automation systems.

FAQ – Frequently Asked Questions

What is the Endress+Hauser FMP54 used for?

The FMP54 guided radar transmitter is used for continuous level measurement of liquids in tanks, vessels, and industrial storage systems.

How does guided radar level measurement work?

Guided radar technology sends microwave pulses along a probe. When the signal reaches the liquid surface, it reflects back to the transmitter, which calculates the level based on the travel time of the signal.

What industries commonly use the FMP54 transmitter?

Industries including oil and gas, chemical processing, water treatment, power generation, and manufacturing commonly use the FMP54 for accurate level monitoring.

What is the maximum measuring range of the FMP53?

The transmitter can measure levels up to 40 meters, depending on the probe type and installation configuration.

Is the FMP54 suitable for harsh industrial environments?

Yes. The transmitter is designed with rugged materials, high ingress protection ratings, and approvals for hazardous areas.

What communication output does the FMP54 support?

The device typically provides 4–20 mA output with HART communication, allowing integration with PLCs, SCADA, and other industrial control systems.

Does the transmitter require frequent maintenance?

No. Guided radar technology requires very little maintenance because the measurement is not affected by many process conditions.
