Description

LS PLC Expansion Module XBF-AD04A

• Extended Product Type : PLC

• Product ID : XBF-AD04A

• LS Type Designation : PLC

Specification of LS XBF-AD04A

• Voltage Range  : DC 0~10V
• Current Range : DC 4~20mA, DC 0~20mA
• Max. conversion speed : 1.5ms / channel
• Max. absolute input volatge : ±15V
• Max. absolute input current : ±25mA
• Analog Input channels : 4 channel/module
• Connection terminal : 11-point terminal block
• Occupied I/O points : Fixed type : 64 points
• Current consumption : DC 5V-120mA, DC 24V-62mA
