Mitsubishi R16SFCPU-SET CPU Safety Kit Bundle Module R16SFCPUSET

• Extended Product Type: PLC
• Product ID: R16SFCPU-SET
• Mitsubishi Type Designation: PLC

Description of Mitsubishi R16SFCPU-SET CPU Safety Kit Bundle

Mitsubishi R16SFCPU-SET Programmable Logic Controller (PLC) safety bundle – kit / bundle (1 x CPU (R16CPU) + 1 x safety function module (R6PSFM)) – SIL2 – (MELSEC iQ-R Series) – 160Ksteps / 640KBytes (Program) memory capacity – connection capacity 4096 x I/O points max – Backplane / rack mounting – equivalent to R16SFCPUSET

Specifications of Mitsubishi R16SFCPU-SET CPU Safety Kit Bundle Module

• Primary brand: Mitsubishi Electric
• Main function: CPU unit
• Product series / family name: MELSEC iQ-R Series
• Functions: Programmable Logic Controller (PLC) safety bundle
  • Control mode — Stored program cyclic operation
  • I/O control mode — Refresh mode
  • I/O control mode — Direct access I/O is available by specifying direct access I/O (DX;DY)
  • Design kit / bundle
• Memory capacity: 160Ksteps / 640KBytes (Program), 1710KBytes (Device/label memory), 10MBytes (Data memory)
• Connection capacity: 4096 x I/O points max
• Mounting mode: Backplane / rack
• Programming languages: Ladder diagram (LD) / Relay symbol language, Structured Text (ST), Function Block Diagram (FBD), Function block (FB), label programming (local/global)
• Contents: 1 x CPU (R16CPU), 1 x safety function module (R6PSFM)
• Manufacturer product status: Commercialized
• Equivalent to: R16SFCPUSET
• Compliant with standard(s): IEC61508 (SIL 3), EN/ISO 13849-1 (PL e), ClassSIL2
