Pepperl+Fuchs Encoder
P+F RVI50N-09BK0A3TN-01000 Encoder RVI50N09BK0A3TN01000
$650.00
AVAILABILITY: Generally allow 7-10 days to ship
Availability: 10 in stock
P+F RVI50N-09BK0A3TN-01000 Encoder RVI50N09BK0A3TN01000
- Extended Product Type: Encoder
- Product ID: RVI50N-09BK0A3TN-01000
- P+F Type Designation: Encoder
Features of P+F RVI50N-09BK0A3TN-01000 Encoder
- Sturdy and compact design
- Up to 2500 ppr
- 4.75 V … 30 V with short-circuit proof push-pull output
Specification of P+F RVI50N-09BK0A3TN-01000 Encoder
- Detection type: photoelectric sampling
- Pulse count: 1000
- Operating voltage: 4.75 … 30 V DC
- Output type: push-pull, incremental
- Connector: type 9416 (M23), 12-pin or type 42306 (M16), 6-pin
- Cable: ∅6 mm, 5 x 0.38 mm2, 0.5 m
- Mass: approx. 220 g
| Weight | 10 lbs |
|---|---|
| Dimensions | 10 × 10 × 10 in |
