Pilz PLC Module 778010

Description

Pilz PLC Module 778010

• Extended Product Type : PLC

• Product ID : 778010

• Pilz Type Designation : PLC

Description

• Safety relay (standalone) Inputs: 2-channel wiring with/without detection of shorts across contacts 4 muting sensors. Outputs: 3 2 N/O, 1 N/C, 5 semiconductor. Automatic/monitored start UB 24 V DC, width: 90 mm, plug-in terminals of screw type Device for the temporary suspension of safety functions, muting, monitoring of muting lamps and their automatic switching

Specification of Pilz 778010

• Application options : Instantaneous E-STOP monitoring
• Operating modes : Dual-channel, Manual reset, Detection of shorts across contacts, without detection of shorts across contacts
• Supply voltage (V) : 24,0
• Supply voltage type : DC
• Number of instantaneous safety contacts : 3
• Number of auxiliary contacts : 1
• Number of semiconductor outputs : 4
• Max. current at DC13 I (6 cycles/min) : 5.0 A
• Voltage at AC15 : 240 V
• Max. current at AC15 : 5.0 A
• Terminal type : Screw terminal
• Terminal style : Plug-in
• Net weight : 565 g
