Yaskawa CIMR-VB2A0020BBA AC Drive 5HP CIMRVB2A0020BBA

$1,640.00

AVAILABILITY: Generally allow 7-10 days to ship

10 in stock

SKU: CIMR-VB2A0020BBA Category: Tag:
Yaskawa

Description

Yaskawa CIMR-VB2A0020BBA AC Drive 5HP CIMRVB2A0020BBA

  • Extended Product Type: AC Drives
  • Product ID: CIMR-VB2A0020BBA
  • Yaskawa Type Designation: AC Drives

Yaskawa CIMR-VB2A0020BBA AC VFD Drive

Yaskawa CIMR-VB2A0020BBA Versatile Variable Speed/Frequency Drive (VSD/VFD) / Inverter – USA region – Yaskawa (V1000 series) – Input voltage (3-phase (3P)) 200Vac-240Vac (208Vac / 220Vac / 230Vac) – Rated active power 5.5kW (Normal duty) / 5HP (Normal duty) – Rated output current 19.6A (Normal duty) – frequency (output) 0.01-400Hz – IP20 / NEMA 1 – with RS-422 + RS-485 communication capability – Wall mounting – Standard heatsink fins – 3-phase 200V class – ordering code CIMRVB2A0020BBA

Specification of Yaskawa CIMR-VB2A0020BBA AC Drive

  • Primary brand: Yaskawa
  • Main function: Variable Speed/Frequency Drive (VSD/VFD) / Inverter
  • Product series / family name: V1000 series
  • Network frequency: (output) 0.01-400 Hz, (input) 50/60 Hz
  • Functions: Versatile Variable Speed/Frequency Drive (VSD/VFD) / Inverter – USA region, Speed search, Over torque detection, Torque limit, 17-step speed, Acceleration/Deceleration time switch, S-curve accel/decel, 3-wire sequence, Auto-tuning, Dwell, Cooling fan on/off switch, Slip compensation, Torque compensation, Frequency jump, Upper/lower limits for frequency reference, DC injection braking at start and stop, Overexcitation braking, High slip braking, PID control, Energy saving control, Fault restart, Application presets
  • Supply voltage (AC): 200Vac-240Vac (208Vac / 220Vac / 230Vac)
  • Display: LED 5-digit display
  • Type of network: 3-phase input (3P)
  • Rated current: 19.6A (Normal duty), 17.5A (heavy duty), 120% / 60s (Normal duty) or 150% / 60s (heavy duty) overload current rating
  • Rated active power (kW): 5.5kW (Normal duty), 4kW (heavy duty)
  • Rated power (HP): 5HP (Normal duty), 5HP (Heavy-duty)
  • Protection functions: Motor overheat, Overcurrent, Overload, Overvoltage, Under voltage, Momentary power loss ride-thru, Overheat, Ground fault
  • Protection settings: (Overcurrent) output current exceeds 200% of heavy duty rating
    • (Overload) 120% of rated output current; normal duty
    • (Overload) 150% of rated output current; heavy duty
  • Communication protocol: RS-422, RS-485
  • Net Height (mm): 153 mm
  • Net Width (mm): 140 mm
  • Net Depth (mm): 143 mm
  • Mounting mode: Wall mounting
  • Digital inputs: 1 x digital input (24Vdc; Sink/Source) (S1 – Forward / Stop)
    • 1 x digital input (24Vdc; Sink/Source) (S2 – Reverse / Stop)
    • 1 x digital input (24Vdc; Sink/Source) (S3 – External fault)
    • 1 x digital input (24Vdc; Sink/Source) (S4 – Fault reset)
    • 1 x digital input (24Vdc; Sink/Source) (S5 – Multi-step speed 1)
    • 1 x digital input (24Vdc; Sink/Source) (S6 – Multi-step speed 2)
    • 1 x digital input (pulse / 32kHz)
    • 1 x digital input (STO)
  • Digital outputs: 1 x digital output (SPDT Single Pole Double Throw contact type) (MA-MB-MC; MC-MB closed means fault)
    • 1 x digital input (Pulse train output; PTO)
  • Analog inputs: 1 x analog input (0-10Vdc) (Analog input 1)
    • 1 x analog input (0-10Vdc) (Analog input 2)
  • Analog outputs: 1 x analog output (2mA / 0-10Vdc) (AM – Monitor output)
  • Degree of protection: IP20, NEMA 1
  • Ambient air temperature for storage: -20…+60 °C
  • Technology used in component: Standard heatsink fins
  • Rated apparent power (S): 7.5kVA (Normal duty), 6.7kVA (heavy duty)
  • Application type: Conveyors, Packaging’s, Fans, Pumps, Foods and beverages, Industrial washers, Compressors
  • Order code / Manufacturer SKU: CIMR-VB2A0020BBA
  • Manufacturer product status: Commercialized
  • Compliant with standard(s): UL 508C, CSA 22.2 No. 14-95, UL, cUL, CE, RoHS, EN 50178 (LVD), EN 50081-2, EN 50082-2 (EMC), EN 954-1, Category 3 Safety Standard EN 61800-3, IEC 60529, IEC 146, FCC CFR 47 Part 15 Subpart B, TUV, IEC 60529
Is there anything like that today, killing someone before the fight really begins? In the second inning, Darren Daulton opened with a double, took third on a ground out, and scored on a Kevin Stocker single. The Biloxi hollywood casino buffet Shuckers world series of poker game app held their no deposit bonus mobile casino second annual job fair Saturday at MGM.

Additional information

Weight14 lbs
Dimensions12 × 12 × 14 in
