Schneider TeSys Deca LC1DT40M7C Contactor 40 A AC 50/60 Hz Coil

• Extended Product Type: Contactor
• Product ID: LC1DT40M7C
• Schneider Type Designation: Contactor

Description of Schneider TeSys Deca LC1DT40M7C Contactor

Schneider LC1DT40M7C TeSys Deca contactor – 4P(4 NO) – AC-1 – <= 440 V 40 A – 220 V AC 50/60 Hz coil

Specification of Schneider TeSys Deca LC1DT40M7C Contactor 40A

• Range of product: TeSys
• Poles: 4P
• Power pole contact composition: 4 NO
• Rated operational voltage: <= 300 V DC for power circuit, <= 690 V AC 25…400 Hz for power circuit
• Control circuit type: AC 50/60 Hz
• Control circuit voltage: 220 V AC 50/60 Hz
• Device short name: LC1D
• Contactor application: Resistive load
• Utilisation category: AC-1
• Poles description: 4P
• Power pole contact composition: 4 NO
• [Ue] rated operational voltage: Power circuit: <= 690 V AC 25…400 Hz, Power circuit: <= 300 V DC
• [Ie] rated operational current: 40 A (at <60 °C) at <= 440 V AC AC-1 for power circuit
• Control circuit type: AC at 50/60 Hz
• [Uc] control circuit voltage: 220 V AC 50/60 Hz
• Auxiliary contact composition: 1 NO + 1 NC
• [Uimp] rated impulse withstand voltage: 6 kV conforming to IEC 60947
• Overvoltage category: III
• [Ith] conventional free air thermal current: 10 A (at 60 °C) for signaling circuit, 40 A (at 60 °C) for power circuit
